SH Burrs - Flame Shape Double Cut Carbide Burr Bits

Priced From
Free shipping on orders $49 and up
*Sort the Table by clicking on the Column Heading
DBdLTypeBall BearingRef #BrandTool NoOur PriceWish ListReady To Buy
1/81/41/81-1/2Solid CarbideNoSH-41DC
Amana Tool BURS-200 Flame Shape SC 1/8 D x 1/4 CH x 1/8 SHK x 1-1/2 Inch Long Double Cut SH Burr BitMore infoAmana ToolBURS-200$8.00$6.00
1/41/21/42Solid CarbideNoSH-1DC
Amana Tool BURS-202 Flame Shape SC 1/4 D x 1/2 CH x 1/4 SHK x 2 Inch Long Double Cut SH Burr BitMore infoAmana ToolBURS-202$20.25$15.19
5/163/41/42-1/2Solid Carbide Head Brazed to Steel ShankNoSH-2DC
Amana Tool BURS-204 Flame Shape SC Head 5/16 D x 3/4 CH x 1/4 SHK x 2-1/2 Inch Long Double Cut SH Burr BitMore infoAmana ToolBURS-204$20.15$15.11
1/21-1/41/43Solid Carbide Head Brazed to Steel ShankNoSH-5DC
Amana Tool BURS-206 Flame Shape SC Head 1/2 D x 1-1/4 CH x 1/4 SHK x 3 Inch Long Double Cut SH Burr BitMore infoAmana ToolBURS-206$46.25$34.69

For Die-Grinders

Benefits of the DC flute include rapid removal of a broad range of materials combined with excellent operator control. It does this by incorporating a positive cutting rake angle that gives great “bite” into the material and yet,­­­ is not so aggressive that the operator fatigues quickly after using it in a hand piece. The steel shanks are ground, which sets them apart from our competitors. The solder joints are clean, with no excess solder gaping out from the sides between the carbide bud and the shank

Applications: To be used with air or electrically driven hand die-grinder with a typical collet mechanism or knee mill with an air-driven spindle speeder such as an Air Turbine product. Use of a quality spindle speeder may greatly improve performance of miniature tooling.

WARNING!: Not to be used in conventional Routers

For use with:

  • Aluminum
  • Brass
  • Bronze
  • Cast Iron
  • Chrome
  • Copper
  • Stainless Steel
  • Steel: 40-55rc
  • Steel: Carbon
  • Steel: Nickel
  • Steel Weldments
  • Titanium

More sizes, shapes & types available upon request.

Tool No.

CNC Feed/Speed

Vectric .tool & Fusion .tools File

AutoCad PDF/DXF File
